DNS-6040M/DNS-6040 User’s Manual
10
TIP
If NAS server supports more than one network card, D-Link NAS
Filer Assistant will show only one of the network cards
for system
administrator to setup. If you wish to setup other network card (s),
system administrator must perform further setup in Storage Manager.
D-Link NAS Filer Assistant Utility display rules as follows:
1、 The first time you setup the NAS server,
D-Link NAS Filer
Assistant Utility
will display the first network card of the
server. If there is a DHCP server the “IP Status” will show
“DHCP”. If there is no DHCP server, then the “IP Status” is
“Unknown”.
2、 If system administrator has already used Storage Manager to
assign IP addresses to (multiple) network cards on the server
and made them belong to different subnets, then
D-Link NAS
Assistant Utility
will show the network card that belongs to the
same subnet with the client computer that runs D-Link NAS
Assistant Utility.
3、 If not one network card in NAS server belongs to the same
subnet as client computer that runs D-Link NAS Filer
Assistant Utility, then Assistant Utility will show the first
network card of the server and the “IP Status” will show
“Unknown”.
Double-click on the server name “NAS001” to open the network
configuration screen.
If your LAN includes a DHCP server, select “Get Network
Configuration through DHCP” to automatically configure the network
through the DHCP server. If no DHCP server is present, or if you
prefer manual configuration, choose “Use Manual Configuration” and
enter an IP address, domain name, subnet mask, gateway, and DNS
server. The setup program will grab the network configuration of the
client for administrator’s reference. If this information is not enough,
choose “Suggestion”; the setup program will check available IPs on
the LAN and provide a suggested IP address.
