DNS-6040M/DNS-6040 User’s Manual
60
Default settings for newly created accounts
Default group: ○ users ○ guests
Here you can choose to which group newly created users
belong by default. If you want new accounts to
automatically have a home folder, choose users, otherwise,
choose guests.
Default quota: ○ _____MB ○ unrestricted
With this setting you can limit the amount of storage
space allotted to new users, or choose not to attach any
restrictions, i.e. unrestriced.
Default home volume: Volume__
If the newly created account belongs to Users group,
please select the volume in which its home folder will be
saved.
Network Setup
Use Network Setup to set the network types supported by the
NAS server. The default setting allows for simultaneous use of
Windows, UNIX, and Apple networks. You may change the
defaults according to your needs.
