DNS-6040M/DNS-6040 User’s Manual
12
Chapter 3
Quick Configuration
D-Link NAS offers a simple and easy-to-use approach to
NAS administration called Storage Manager. Use this program
to configure the server, system and network parameters,
including Windows, UNIX, Novell and Apple Macintosh
network settings, as well as the hard disk configuration.
When you first install the NAS server,
D-Link NAS Filer
Assistant
will complete the IP configuration of the server and
then automatically open a browser window to connect to the
server. The Quick Configuration page with basic configuration
options will appear.
TIP
During setup, watch the tips on the right hand side of the browser
window or refer to this user‘s guide for more information.
This system only supports Microsoft IE 5.0 browsers or above.
Netscape browsers are not supported.
