DNS-6040M/DNS-6040 User’s Manual
139
Windows domain does not exist while restoring, probably
due to the disconnection of the domain or the PDC being
down, the Windows domain information cannot be
restored properly.
Error code 3: the NAS server has already been integrated into another
Windows domain while restoring data, this will automatically lead to
failure of re-integrating into the original Windows domain.
If the NAS server is integrated into the Windows domain
while backing up, the Windows domain information will
be backed up simultaneity. Restoring the Windows
domain information can be done simultaneously with
restoring data back on to NAS server at a later date. If the
NAS server has already been integrated into another
Windows domain while restoring, the system cannot be
re-integrated into the original Windows domain.
Error code 4: the storage space on the NAS server is not sufficient to
restore data, restoring of files has been discontinued.
Error Code 5: the network is suddenly disconnected or the user clicks
on “Cancel” to stop the operation when backing up/restoring the
data.
General Problems
How to deal with lost passwords
If a user has forgotten his/her password, he/she can turn to the
system administrator to reset the personal settings. If the system
