DNS-6040M/DNS-6040 User’s Manual
134
If all the above settings are correct, please reboot the NAS server.
Cross marks appear when an Apple client is browsing an English
web site
When an Apple client, for example a Mac OS 9.0.2 client,
is trying to browse an English web site and sees many
“cross”marks appear, please close Smartview from the Control
Panel.
Apple clients cannot execute files saved by Windows clients to
the NAS server directly
Apple and Windows clients can share the same folder.
However, since Apple and Windows systems handle file
associates in different ways, the access to the files supported by
both Apple and Windows systems such as “pdf” and “html”
may be restricted.
For example, when a Windows client saves an html file to the
NAS server, an Apple client cannot double-click this file on the
server to open the file by automatically launching the web
browser. Because the way Windows system saves “Associated
file type” differs from that of Apple, Apple system does not
know with what program it can open the html file created in
Windows. There are two solutions:
Re-establish the associate of this file on the Apple client.
Launch the program used for executing the file on the Apple client first.
In this case launch IE or Netscape and then open the file with the
browser. Alternatively, use “save as” to save the file on the Apple
