DNS-6040M/DNS-6040 User’s Manual
135
client so that the new file will be saved in the Apple format. To open
the file, simply double-click it.
The same solution can be applied to the problem happening
when the Windows client cannot directly execute files saved by
the Apple client to the NAS server.
HDD space is not released after an Apple client deletes a file on
the NAS server
When an Apple client deletes a file on the NAS server, the
file is not actually deleted so the available HDD space shown on
the Server Information/Status page is not enlarged. To release
the space, use “Empty Trash” on the Apple client’s terminal.
Windows clients cannot delete files saved by Apple clients to the
NAS server
The Apple system allows the last digit of the file name to
be a space while the Windows system does not accept such a
format. Thus when the Apple client saves a file of this format
to the NAS server, the Windows client cannot delete the file for
it is unrecognizable. It is suggested that Apple users avoid
creating files with a space at the end of the file name if they
have to share files on the NAS server with Windows clients.
Problems about Setting the Storage Manager
Storage Manager lost connection to client terminal
If due to heavy network traffic
Storage Manager
fails to
respond or freezes while running setup, try clicking on another
