DNS-6040M/DNS-6040 User’s Manual
136
section, then on the original section again. If this doesn’t work,
close the browser window and re-open Storage Manager.
Cannot connect to NAS after modifying network configuration
After modifying the network configuration (including
server addresses, domain, DNS entries, etc.), re-confirm the
network settings and change them as necessary. Try closing the
browser and reconnecting to Storage Manager.
If
D-Link NAS Filer Assistant
Utility
cannot find the
server due to incorrect network settings, press the IP reset button
on the rear panel of the server to clear the incorrect
configuration settings, and then use Assistant Utility to search
again.
Local users cannot access Storage Manager
Possible reasons a user’s account on the local machine
cannot connect to the Storage Manager may include:
The account was originally a Windows PDC account. The system
administrator did not setup a password when adding it to the local
accounts.
If the client platform is using a language different from the one used
on
Storage Manager
, then the client might be reading random codes
when using the system. The system administrator has to re-set the
languages on Storage Manager so that they are readable by the client.
E-mail notifications not received
If you don’t receive e-mail notifications from the server, go
to Storage Manager, Server Information
System Log, and
