DNS-6040M/DNS-6040 User’s Manual
148
#Mount point Mount options File system
/usr/local -ro,nosuid dogfood:/volume1/programs
/public -rw datakey:/volume1/public1
The first column is the mount point and the second column
represents the mounting parameters. The third column shows the
NFS file system in use. For example, if users of Unix clients
want to access the files in /usr/local, /usr/local will
automatically link to dogfood:/volume1/programs based on
auto_direct.
The other database “auto_home” can have different links
according to different user names. Its format is:
#User name File system
sysadmin dogfood:/volume1/homes/sysadmin
justind dogfood:/volume1/homes/justind
anneli datakey:/volume1/users/anneli
jiem dadakey:/volume1/users/&
Assume that /etc/passwd (the file holding the user accounts) on
the NIS server has the following content:
sysadmin:x:1000:500:System
Administrator:/home/sysadmin:/bin/tcsh
justind:x:1001:500:Justin Deng:/home/justind:/bin/tcsh
anneli:x:1002:500:Anne Li:/home/anneli:/bin/tcsh
jiem:x:1003:500:Jiem Deng:/home/jiem:/bin/csh
When the user sysadmin logs in to the Unix clients, he will enter
