DNS-6040M/DNS-6040 User’s Manual
47
on the NAS server.
By default Windows domain accounts do not have home
folders. If you wish to assign a home folder to this type of
account, simply select the desired account on the left (use Ctrl
for multiple and Shift for continuous selection), then click on
Add to local. The selected accounts will appear in the list of
local users. By default, they are part of the guests group. First
setup the passwords for the accounts, then transfer these
accounts from the guests group to the users group, and select the
User home volume location .
Additionally, Windows domain account will directly apply
the default settings for all newly created users defined in
Security Option. The system administrator can setup hard disk
quota for each individual NT domain account in Quota Option.
