DNS-6040M/DNS-6040 User’s Manual
63
the account and password information to the Windows PDC
server for verification. If the result is positive, access will be
granted. If the PDC server does not authorize the user, the
account is verified against the list of local users. Access is
granted if the login data corresponds to a local user.
Note that accounts with the same name on both PDC and
the NAS server will be merged automatically. For example, if an
account user1 exists on both the PDC and the NAS server, but
with different passwords, access is granted if either one of the
two passwords is provided. The system administrator should,
however, avoid allowing accounts existing on the Windows
PDC to be created on the NAS server. A situation where
different users share the same account name should also be
avoided.
