![Verto 50G285 [12/100] Operation settings](/views2/1569892/page12/bgc.png)
12
WARNING
ASSEMBLY / SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Battery - 2 pcs
2. Charger - 1 pce
3. Driver bits - 6 pcs
4. Bit holder - 1 pce
5. Drills - 6 pcs
6. Carrying case - 1 pce
PREPARATION FOR OPERATION
REMOVING AND INSERTING THE BATTERY
• Set the direction selector switch (3) in middle position.
• Push battery lock button (5) and slide out the battery (4)
(fig. A).
• Insert charged battery (4) into the handle holder, you
should hear when the battery lock button (5) snaps.
BATTERY CHARGING
Drill is supplied with partially charged battery. The battery
should be charged in ambient temperature between 4°C
and 40°C. New battery, or one that has not been used for a
long time, will reach full efficiency after approximately 3 to
5 charge/discharge cycles.
• Remove the battery (4) from the drill (fig. A).
• Connect the charger (10) to mains socket (230 V AC).
• Take the charger (10) plug and slide it into the charger
socket (9) located on the battery (4) (fig. B).
When the charger is connected to power supply, the LED
(11) of the charger (10) turns on in green. LED lighting
scheme is described below.
• Diode on green – indicates voltage on the connector.
• Diode on red – charging is in progress (once the battery
is connected to the charger).
• Diode on green again – the battery is fully charged.
Once the battery has been charged, the LED diode (11)
is lit green until you disconnect the charger from mains
network.
Batteries heat up strongly when charging. Do not
operate just after charging – wait for the battery to
cool down to room temperature. It will prevent battery
damage.
SPINDLE BRAKE
Drill is equipped with electronic brake that stops the
spindle immediately after the switch button (6) is released.
The brake ensures precision when screwing or drilling and
prevents free spindle rotation after switching off.
OPERATION / SETTINGS
SWITCHING ON / SWITCHING OFF
Switching on – press the switch button (6).
Switching off – release the switch button (6).
Each time the switch button (6) is pressed, the LED diode
(7) lights up to illuminate the workplace.
ROTATIONAL SPEED CONTROL
Increase or reduce pressure on the switch button (6) to
adjust drilling or driving speed while operating. Speed
adjustment allows for a soft start, which prevents dill
slipping when drilling holes in gypsum or glaze, and allows
for operation control when screwing in and out.
OVERLOAD CLUTCH
Set the torque adjustment ring (2) in appropriate position
to permanently set overload clutch to defined torque
value. When the set torque is reached, overload clutch
disconnects automatically. It prevents screwing screws too
deep or damaging the drill.
TORQUE ADJUSTMENT
• Different screws and materials require different torque
to be applied.
• The bigger the number corresponding to given position,
the bigger is the torque (fig. C).
• Set the torque adjustment ring (2) to appropriate torque
value.
• Always start operation with low torque.
• Increase the torque gradually until obtaining desired
results.
• Use higher settings to unscrew screws.
• When drilling, choose setting marked with the drill
symbol. The torque is the greatest with this setting.
• Knowledge how to choose appropriate torque setting
comes with practice
Setting the torque adjustment ring in the drilling
position deactivates the overload clutch.
WORKING TOOL INSTALLATION
• Set the direction selector switch (3) in the middle
position.
• Hold the rear ring of the quick release chuck (1) and turn
the front ring counter clockwise. Turn until jaws spread
properly and allow to insert drill or driver bit (fig. D).
• Hold the rear ring of the quick release chuck (1), turn
front ring clockwise and tighten firmly to install work
tool.
Deinstallation of tool is similar to installation, only the
sequence of actions is reversed.
Make sure the tool position is correct when installing
drill or driver bit in the quick release chuck. Use
additional magnetic adapter as an extension when
using short driver bits.
LEFT RIGHT DIRECTION OF ROTATION
Choose direction of spindle rotation with the direction
selector switch (3) (fig. E).
