MEAN WELL CLG-150-20A [15/100] Lpc 60 lpc 150 lpc 100

MEAN WELL ELG-75-36AB [15/100] Series
LPC-60 LPC-150LPC-100
INPUT
60W / 100W 150W
OUTPUT
60W / 100W 150W
12
LPC-60 Series
LPC-100 Series
LPC-150 Series
Features
• Constant current mode
• LPC-60/100: 90~264VAC input
LPC-150: 180~305VAC input only
• High efficiency up to 90%
• Fully encapsulated with IP67 level
• Isolation class II, no F.G.
• Class 2 power unit / Pass LPS (LPC-60)
Model No. Output Io Tol. R&N Effi.
LPC-60-1050 9~48V, 1050mA ±5% 200mV 87%
LPC-60-1400 9~42V, 1400mA ±5% 200mV 85%
LPC-60-1750 9~34V, 1750mA ±5% 200mV 87%
Model No. Output Io Tol. R&N Effi.
LPC-100-350 143~286V, 350mA ±5% 1.5V 90%
LPC-100-500 100~200V, 500mA ±5% 1.5V 90%
LPC-100-700 72~143V, 700mA ±5% 1.0V 90%
LPC-100-1050 48~96V, 1050mA ±5% 1.0V 90%
LPC-100-1400 36~72V, 1400mA ±5% 1.0V 89.5%
LPC-100-1750 29~58V, 1750mA ±5% 1.0V 89.5%
LPC-100-2100 24~48V, 2100mA ±5% 1.0V 89%
Model No. Output Io Tol. R&N Effi.
LPC-150-350 215~430V, 350mA ±5% 2.0V 90%
LPC-150-500 150~300V, 500mA ±5% 1.5V 90%
LPC-150-700 107~215V, 700mA ±5% 1.0V 90%
LPC-150-1050 72~144V, 1050mA ±5% 1.0V 90%
LPC-150-1400 54~108V, 1400mA ±5% 1.0V 90%
LPC-150-1750 43~86V, 1750mA ±5% 1.0V 90%
LPC-150-2100 36~72V, 2100mA ±5% 1.0V 90%
LPC-150-2450 31~62V, 2450mA ±5% 1.0V 90%
LPC-150-2800 27~54V, 2800mA ±5% 1.0V 90%
LPC-150-3150 24~48V, 3150mA ±5% 1.0V 90%
AC input voltage range 90~264VAC; 127~370VDC 180~305VAC; 254~431VDC
AC inrush current (max.) Cold start, 60A at 230VAC Cold start, 75A at 230VAC Cold start, 40A at 230VAC
Over voltage protection 105%~135% 110%~135%
Withstand voltage I/P-O/P: 3kVAC
Working temperature -30~+70
O
C -25~+50
O
C -25~+50
O
C
Vibration 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
Safety standards UL1310, EAC TP TC 004 approved EN62368-1(LVD), EAC TP TC 004 approved
EMC standards EN55032 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EAC TP TC 020
Connection
Input
UL rated, 18AWG x2C (60cm) UL rated, 18AWG x2C (30cm) UL rated, SJTW 18AWG x2C (30cm)
Output
UL rated, 16AWG x2C (60cm) UL rated, 18AWG x2C (30cm) UL rated, SJTW 18AWG x2C (30cm)
Dimension (LxWxH)(mm) 162.5x 42.5x 32 190x 52x 37 191x 63x 37.5
• Economic, high reliability
• Suitable for LED-based decorative / architectural lighting,
LED stage, theater lighting, and LED electronic displays
• Protections: Short circuit / Over voltage /
Over temperature (LPC-150 only)
• 2 years warranty
(for 1750mA)
(for 1050mA & 1400mA)
Note: The models on this page might not be suitable for lighting applications in EU countries. Please check with your local authorities for the possible use of
the model of interest.
se
ri
es
60~150
W
