Features
• Constant voltage + Constant current mode output
• Universal AC input 110~305VAC input
• Plastic housing with Class II design
• Built-in active PFC function
• Class 2 power unit (Except for SLD-80-12)
• Slim and Linear housing Design
AC input voltage range 110~305VAC; 154~431VDC
AC inrush current (max.) Cold start, 50A at 230VAC
Setup time 500ms at 230VAC
Total harmonic distortion THD< 10%
Short circuit protection Hiccup mode, recovers automatically after fault condition is removed
Over temp. protection Shut down output voltage, re-power on to recover
ved
Withstand voltage I/P-O/P: 3.75KVAC
Working temperature
Tcase=-20~+90˫ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)
Safety standards
UL8750(type”HL”),CSA C22.2 No. 250.13-12, ENEC EN61347-1, EN61347-2-13 independent, EN62384,
EAC TP TC 004, GB19510.1,GB19510.14,IP67 approved
EMC standards
EN55015,EN61000-3-2 Class C (@load͘60%) ; EN61000-3-3;GB17743 and GB17625.1, EN61000-4-
2,3,4,5,6,8,11; EN61547, light industry level (surge immunity Line-Line 1KV),EAC TP TC 020
Dimension (LxWxH)(mm) 280x 30x 16.8 320x 30x 16.8
• No load power consumption<0.5W
• Protections: Short circuit / Over current / Over voltage /
Over temp.
• Complian with EN61347 regulation
• 3 years warranty
SLD-80 Series
SLD & LDC Linear series Selection
SLD-50 Series
Model No. Output Tol. R&N Effi.
SLD-80-12 7.2~12V, 6.6A ±4% 150mV 88%
SLD-80-24 14.4~24V, 3.3A ±3% 240mV 90%
SLD-80-56 30~56V, 1.4~2.1A ±1% 350mV 90%
12V 24V 56V 0-10V DALI Push Dim warranty
LDC-35 √ √ √ √ 5
LDC-55 √ √ √ √ 5
LDC-80 √ √ √ √ 5
SLD-50 √ √ √ 3
SLD-80 √ √ √ 3
Model No. Output Tol. R&N Effi.
SLD-50-12 7.2~12V, 4.2A ±4% 150mV 88%
SLD-50-24 14.4~24V, 2.1A ±3% 240mV 90%
SLD-50-56 30~56V, 0.9~1.4A ±1% 350mV 90%
se
ri
es
5
5
0~80
W
Type HL Type HL
Model
output
Application Diagram
źź
56V output is C.P mode output
*
