46
ELG-240-C Series
Model No. Output Tol. Io Ripple Effi.
ELG-240-C700 A -
172~343V, 700mA ±5.0% 5% 93%
ELG-240-C1050 A -
114~228V, 1050mA ±5.0% 5% 93%
ELG-240-C1400 A -
86~171V, 1400mA ±5.0% 5% 93%
ELG-240-C1750 A -
69~137V, 1750mA ±5.0% 5% 93%
ELG-240-C2100 A -
57~115V, 2100mA ±5.0% 5% 93%
= Blank, A, B, AB, D2 or DA ; = Blank, 3Y
0-10VDC
(DA-Type)(B-Type)
(for 700A, 1050A ony)
AC input voltage range
100~305VAC; 142~431VDC
AC inrush current (max.) Cold start 75A at 230VAC Cold start 45A at 230VAC
Current adjustment range 50%~100% via potentiometer
(A/AB-Type only)
32.5%~100% via potentiometer(A/AB-Type only)
Over voltage protection 105%~145% rated output voltage
Over temperature protection Shut down o/p voltage, re-power on to recover
Tcase>85˫±5˫,derate power automatically by 6%/˫max
Setup time 800ms/115VAC, 500ms/230VAC 500ms at 230VAC and 115VAC
Withstand voltage I/P-O/P:3.75kVAC I/P-FG: 2kVAC O/P-FG: 1.5kVAC
Working temperature Tcase=-40~+85
O
C (refer to "OUTPUT LOAD vs TEMPERATURE")
Safety standards
UL8750(type“HL”), CSA C22.2 No. 250.13-12, ENEC EN61347-1, EN61347-2-13 independent; AS/
NZS 61347-1,AS/NZS 61347-2-13 independent,EN62384, EAC TP TC 004,
KC61347-1, KC61347-2-13,
GB19510.14,GB19510.1
EMC standards
EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,6,8,11, EN61547; GB17743, GB17625.1,
EAC TP TC 020,KC KN15, KN61547
Connection Please refer to page 47
Dimension (LxWxH) (mm) 244x 71x 37.5 246x 77x 39.5
Features
• Constant power mode (for ELGC-300)
• Constant current mode output (for ELG-240-C)
• Universal AC input (100 to 305VAC) / Full range
• High efficiency up to 94.5%
• Standby power consumption<0.5W(for ELG-240-C)
• Meet 6KV surge immunity level (IEC61000-4-5)
• Type HL LED driver for use in Class I, Division 2 hazardous
location luminaires
• Suitable for dry / damp / wet locations
• Suitable for outdoor LED lighting applications
• Protections: Short circuit / Over voltage / Over temperature
• Multiple models for choice:
Blank-Type:
IP67 rated. Cable for I/O connection(For harsh environment)
A-Type: IP65 rated. Io and Vo adjustable through built-in
potentiometer
B-Type: IP67 rated. 3 in 1 dimming function (0~10Vdc, 10V PWM
signal and resistance)
AB-Type: IP65 rated. Io adjustable through built-in
potentiometer
& 3 in 1 dimming function.
D2-Type: IP67 rated.
Smart timer dimming function*, contact
MEAN WELL for details
DA-Type: IP67 rated. DALI control technology
• 5 years warranty
ELGC-300 Series
Model No. Vout
Iout(mA)
Tol. Io Ripple Effi.
100~180VAC 200~305VAC
ELGC-300-L-
116~232V 650~1700 650~2000 ±5% 5% 94.5%
ELGC-300-M-
58~116V 1300~3400 1300~4000 ±5% 5% 93.5%
ELGC-300-H-
29~58V 2600~6800 2600~8000 ±5% 5% 92.5%
= Blank, A, AB, D2 or DA
0-10VDC
(DA-Type)
(B-Type)
