MEAN WELL CLG-150-20A [34/100] Series
![MEAN WELL ODLC-45A-700 [34/100] Series](/views2/1675311/page34/bg22.png)
LCM-40KNLCM-25KN
INPUT
OUTPUT
NEWNEW
NEWNEW
NEWNEW
N
E
N
N
N
E
E
E
W
W
31
Features
AC input voltage range 180 ~ 277VAC; 220 ~ 417VDC 180 ~ 295VAC; 220 ~ 417VDC
AC inrush current (Typ.) COLD START, 20A at 230VAC; Per NEMA 410
Short circuit protection Constant current limiting, recovers automatically after fault condition is removed
Over voltage protection --- 110 ~ 130V 105 ~ 125V
Over temperature protection Shutdown o/p voltage,re-power on to recover
Setup time 500ms / 230VAC
Total harmonic distortion THD< 20%
Withstand voltage I/P-O/P:3.75KVAC
Working temperature
Tcase= -30~+85˫
90˫
Safety standards
CSA C22.2 No.250.13-12(LCM-25KN only); ENEC EN61347-1, EN61347-2-13, EN62384 independent,
GB19510.14,GB19510.1, EAC TP TC 004 approved
KNX standards Certied protocol
EMC standards
EN55015, EN61000-3-2 Class C(@load͘40%) ; EN61000-3-3; GB17625.1,GB17743,EN61000-4
-2,3,4,5,6,8,11, EN61547, light industry level(surge immunity Line-Line 2KV), EAC TP TC 020
Dimension (LxWxH)(mm) 105x 68x 23 123.5x 81.5x 23
• Constant current mode output
• KNX protocol
• Multiple-stage output current le
vel selectable by DIP switch
• support emergency lighting(EL)
• Integrated constant light output
• Integrated
KNX push button interface
• synchronization up to 10units
Output I o Tol. Io Ripple Ef.
DIP Switch
123456
350mA, 2~100V
±5%
5%
(max.)
90%
----- ----- ----- ----- ----- -----
500mA, 2~80V ON ----- ----- ----- ----- -----
600mA, 2~67V ON ON ----- ----- ----- -----
700mA, 2~57V (Factory setting) ON ON ON ----- ----- ON
900mA, 2~45V ON ON ON ON ----- ON
1050mA, 2~40V ON ON ON ON ON ON
Output I o Tol. Io Ripple Ef.
DIP Switch
123456
350mA, 6~54V
±5%
5%
(max.)
86%
----- ----- ----- ----- ----- -----
500mA, 6~50V ON ----- ----- ----- ----- -----
600mA, 6~42V ON ON ----- ----- ----- -----
700mA, 6~36V (Factory setting) ON ON ON ----- ----- ON
900mA, 6~28V ON ON ON ON ----- ON
1050mA, 6~24V ON ON ON ON ON ON
Output Io Tol. Io Ripple Ef.
DIP Switch
123456
500mA, 2~90V
±5%
5%
(max.)
91%
----- ----- ----- ----- ----- -----
600mA, 2~90V ON ----- ----- ----- ----- -----
700mA, 2~86V (Factory setting) ON ON ----- ----- ----- -----
900mA, 2~67V ON ON ON ----- ----- ON
1050mA, 2~57V ON ON ON ON ----- ON
1400mA, 2~42V ON ON ON ON ON ON
LCM-40KN Series
LCM-25KN Series
LCM-60KN Series
LCM-60KN
• Multiple models for choice:
Blank-Type: KNX and push dimming, with standby power
consumpion<0.5W
AUX-Type: KNX and push dimming, with standby power
consumpion<1.2W and Auxiliary DC outpt
• Protections: Short circuit / Over voltage / Over temp.
• 3 years warranty
se
r
ies
25
25
2
~6
~6
~
0
0
0
0
0
W
W
W
W
W
W
