HLG-60H-C HLG-80H-C
HLG-120H-C
INPUT
OUTPUT
(Non-Dimming
Models)
OUTPUT
(Dimming
Models)
Vo
-
DIM
-
DIM+
Vo
-
Vo+
Vo
+
ACN
ACL
FG
B / AB
B / AB
53
Model No. Output Io Tol. Io Ripple Effi.
HLG-80H-C350 A 167~257V, 350mA
±5% 8% max.
91.5%
HLG-80H-C700 A 84~129V, 700mA
±5% 8% max.
91.5%
= A, B, AB or D
Model No. Output Io Tol. Io Ripple Effi.
HLG-120H-C350 A 215~430V, 350mA
±5% 8% max.
94%
HLG-120H-C500 A 150~300V, 500mA
±5% 8% max.
94%
HLG-120H-C700 A 107~215V, 700mA
±5% 8% max.
94%
HLG-120H-C1050 A 74~148V, 1050mA
±5% 8% max.
94%
HLG-120H-C1400 A 54~108V, 1400mA
±5% 8% max.
93.5%
= A, B, AB or D
Model No. Output Io Tol. Io Ripple Effi.
HLG-60H-C350 A 100~200V, 350mA
±5% 5% max.
91%
HLG-60H-C700 A 50~100V, 700mA
±5% 5% max.
90.5%
= A, B, AB or D
AC input voltage range 90~305VAC; 127VDC~431VDC
AC inrush current (max.) Cold start, 60A at 230VAC Cold start, 50A at 230VAC
Current adjustment range
60%~100% via potentiometer (A-Type only) 50%~100% via potentiometer (A-Type only)
Short circuit protection Hiccup mode, auto-recovery Constant current limiting, auto-recovery
Over voltage protection 110%~140%, shut down o/p voltage, re-power on to recover
Over temp. protection Shut down o/p voltage, re-power on to recover Shut down o/p voltage, auto-recovery
Setup time 500ms at full load and 230VAC
Withstand voltage I/P-O/P:3.75kVAC, I/P-FG:2kVAC, O/P-FG:1.5kVAC
Working temperature
-40~+80
O
C (refer to "OUTPUT LOAD vs TEMPERATURE") -40~+90
O
C (refer to "OUTPUT LOAD vs TEMPERATURE")
Safety standards
UL8750, GB19510.14, GB1950.1, EAC TP TC 004, EN/AS/NZS61347-1,-2-13, PSE J61347-1,
J61347-2-13 approved
EMC standards
EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, GB17743,
GB17625.1, EAC TP TC 020
Connection Please refer to page 64
Dimension (LxWxH)(mm) 171x 61.5x 36.8 195.6x 61.5x 38.8 220x 68x 38.8
• Constant current mode
• Universal AC input (90 to 305VAC)/ Full range
• High efficiency up to 94%
• Suitable for dry, damp, and wet location
• Suitable for outdoor LED lighting applications
• Protections: Short circuit / Over voltage / Over temperature
• 7 years warranty
• Multiple models for choice:
A-Type: IP65 rated. Io adjustable through built-in potentiometer
B-Type: IP67 rated. 3 in 1 dimming function (1~10Vdc, 10V PWM
signal and resistance)
AB-Type: IP65 rated. Io adjustable through built-in potentiometer
& 3 in 1 dimming function.
D-Type (option): IP67 rated. Timer dimming function,
contact MEAN WELL for details
Features
HLG-60H-C Series (70W)
HLG-120H-C Series (150W)
HLG-80H-C Series (90W)
A
A
D
D
1-10VDC
1-10VDC
1-10VDC
(AB/B-Type)
(AB/B-Type)
(AB/B-Type)
se
ri
es
60
~1
1
1
20
2
20
0
20
0
2
2
0
0
2
2
2
2
0
0
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
