XLG-25 XLG-50
38
AC input voltage range 100~305VAC; 142~431VDC
AC inrush current (max.) Cold start, 50A at 230 VAC
Over power protection 110-150% Over Power Protection, recovers automatically after fault condition is removed
Over temp. protection Hiccup mode, recovers automatically after fault condition is removed
Setup, rise time 500ms, 100ms/115VAC, 230VAC
Withstand voltage I/P-O/P:3.75KVAC I/P-FG:2.0KVAC O/P-FG:1.5KVAC
Working temperature Tcase= -40~+85
O
C Tcase=-40 ~ +90
O
C
Safety standards
UL8750(type”HL”), CSA C22.2 No. 250.13-12; ENEC AS/NZS IEC EN61347-1, AS/NZS EN61347-2-13 inde-
pendent, EN62384;IP67; GB19510.1, GB19510.14 approved
EMC standards
EN55015,EN61000-3-2 Class C (@load͘50%) ; EN61000-3-3; GB17743, GB17625.1,EN61000-4-2,3,4,5,6,8,11;
EN61547, (surge immunity Line-Earth 6KV, Line-Line 4KV)
Connection
Input
SJOW 17AWGx3C & H05RN-F 3x1.0mm
2
(30cm)
Output
A-Type：SJOW 17AWGx2C &
H05RN-F 2x1.0mm
2
(30cm)
AB-Type：
SJOW 17AWGx2C & H05RN-F 2x1.0mm
2
(30cm)+UL2517 20AWGx2C(35cm)
Dimension (LxWxH) (mm) 105x 63x 30
Features
• Constant power mode output
•
Wide input range 100~305VAC (Class I)
• Metal housing design with functional ground
• Built-in active PFC function,Class 2 power unit
• Surge protection with 6KV/4KV
• India (EESL) version with Input Over Voltage Protection can
survive input voltage stress of 440Vac for 48 hours
• 5 years warranty
• Multiple models for choice:
A-Type：IP67 rated. Io adjustable through built-in potentiometer
AB-Type：IP67 rated. Io adjustable through built-in potentiometer
& 3 in 1 dimming function.
• Protections： Over power/Short circuit / Over temperature
/Input over voltage(only for India version )
• IP67 rating for indoor or outdoor installations
XLG-25 Series
XLG-50 Series
Model No. Output I
0
Ripple Effi.
XLG-25 - 22~54V, 0.25 ~ 1.05A 5%(max.) 88%
Model No. Output I
0
Ripple Effi.
XLG-50 - 22~54V, 0.53 ~ 2.1A 5%(max.) 90%
= Blank,I; Blank: For standard version, I:For India version
= A, AB
Note 1:Products sourced from the Americas regions may not have the PSE/
CCC/BIS/KC logo. Please contact your MEAN WELL sales for more information
se
ri
es
25~5
0W
Type HL
Type HL
XLG family selection guide
12V 24V L type M type H type
XLG-25 250~1050 mA
XLG-50 530~2100 mA
XLG-75 5A 3.1A 350~1050 mA 650~2100 mA
XLG-100 8A 4A 350~1050 mA 875~2780 mA
XLG-150 12.5 A 6.25A 350~1050 mA 700~2100 mA 1400~4100 mA
XLG-200 16A 8.3A 350~1050 mA 1750~5500 mA
XLG-240 18A 10A 350~1050 mA 700~2100 mA 2200~6600 mA
P S
E
P S
E
Note.1
Note.1 Note.1 Note.1
Note.1
Model
output
12V/24V with C.V+C.C mode
*
