MEAN WELL CLG-150-20A [85/100] Series
![MEAN WELL XBG-160-A [85/100] Series](/views2/1675311/page85/bg55.png)
NEWNEW
se
ri
es
Sur
g
e Protection De
vi
i
ce
c
82
Model No. SPD-10-320S SPD-10S-277S
Operating voltage
120~320VAC, 50/60Hz 150~510VAC, 50/60Hz
MCOV (Max. continuous operating voltage) 320VAC 277VAC
Continuous Current (max.) 5A 3.5A
UP (Voltage protection level)
L-N:1200V
L-G/PE: 1500V
N-G/PE: 1500V
L-N: 1260V
L-G: 1260V
N-G: 1300V
IN (Nominal discharge current) 5kA,8/20μs
Max. surge current (8/20μs) 10kA,8/20μs
Operating temperature
-40~+70˫ -40~+85˫
Safety standard IEC61643-11: 2011, IEC61000-4-5: 2005 UL1449 Type 4, EN/IEC 61643-11
Model No. SPD-20-240P SPD-20-277P SPD-20HP-277S SPD-20HP-480S
Operating voltage 240VAC, 50/60Hz 277VAC, 50/60Hz 120~277VAC, 50/60Hz 347~480VAC, 50/60Hz
MCOV (Max. continuous operating voltage) 300VAC 320VAC 510VAC
MLV (Measured limiting voltage) ---
L-N:810V, L-G:1560V,
N-G: 1570V
L-N:1400V, L-G:1560V,
N-G: 1570V
VPR (Voltage protection rating) ≤1500V (L-FG, N-FG, L-N) ---
UP (Voltage protection level) ---
L-N:1000V, L-G/PE:3800V,
N-G/PE: 2900V
---
IN (Nominal discharge current) 5kA 10kA
Max. surge current (8/20μs) 20kA
SCCR (Short circuit current rating) 5kA ---
Response time <25ns ---
Operating temperature -40~+70
O
C -40~+75
O
C
Safety standard
UL1449 3
rd
Edition,
TUV EN61643-11 approved
UL1449 3
rd
Edition
approved
UL1449 4
th
Edition,
EN61643-11 approved
UL1449 4
th
Edition
approved
Connection [L (Black)/N (White)/FG (Green)] FEP 10AWG (15cm) ---
10kA Surge Protection Device
20kA Surge Protection Device
• UL1449, Type 4, EN/IEC61643-11(SPD-10S)
• Line to Ground & Line to Line protected
• Series connection type
•LED status indicators
•IP67 (SPD-10-320S); IP66 (SPD-10S)
• Suitable for surge protection of LED drivers
• Thermally protected
• UL1449, Type 2 (SPD-20), Type 4 (SPD-20HP) component assemblies
• Line to Ground & Line to Line protected
• Parallel (3 wires) connection style (SPD-20)
• Series connection style (SPD-20HP)
•LED status indicators
•IP67 (SPD-20); IP66 (SPD-20HP)
• Suitable for surge protection of LED drivers
• Thermally protected (SPD-20HP)
90x 70x 50 mm
(LxWxH)
56.76x 46.36x 26 mm
(LxWxH)
85x 37x 40 mm
(LxWxH)
71.6x 67.7x 32 mm
(LxWxH)
(SPD-20-240P)
(SPD-20HP-277S)
(SPD-10S) (SPD-10S) (SPD-10S)
(LVD)
SPD-20
SPD-10-320S SPD-10S-277S
SPD-20HP
N
E
W
N
NN
E
E
E
W
W
W
56 76x 46 36x 26 mm
