80
Features
• Constant current step-down mode (LDD-H) ;
Constant current buck-boost mode (LDB-L)
• Wide input and output voltage range
• High efficiency up to 97%
• Comply with EN55015 and FCC part 15
without additional input filter and capacitors
Model No.
Input
(VDC)
Output
Io Tol. Ef.
Voltage
(VDC)
Current
(mA)
LDD-300H 9~56 2~52 300 ±4% 97%
LDD-350H 9~56 2~52 350 ±4% 97%
LDD-500H 9~56 2~52 500 ±4% 97%
LDD-600H 9~56 2~52 600 ±4% 97%
LDD-700H 9~56 2~52 700 ±4% 97%
LDD-1000H 9~56 2~52 1000 ±4% 97%
LDD-1200H
9~52 2~46 1200 ±5% 95%
LDD-1500H
9~52 2~46 1500 ±5% 96%
= Blank, W, S ; Blank: pin style, W: wire style, S: SMD style
= Blank, W ; Blank: pin style, W: wire style
Model No.
Input
(VDC)
Output
Io Tol. Ef.
Voltage
(VDC)
Current
(mA)
LDB-300L
9~36 2~40 300 ±5% 90%
LDB-350L
9~36 2~40 350 ±5% 90%
LDB-500L
9~30 2~32 500 ±5% 91%
LDB-600L
9~28 2~30 600 ±5% 91%
= Blank, W ; Blank: pin style, W: wire style
LDD-300~1000H/HW/HS
LDD-1200/1500H/HW
• PWM dimming and remote ON/OFF control
• Protections: Short circuit / Over temperature
• Fully enclosed plastic case (UL 94V-0)
• 3 years warranty
Output current accuracy
±3% at 24VDC input;
±4% at 48VDC input for LDD-H/HW;
±5% at 48VDC input for LDD-HS
±5%
PWM
dimming &
ON/OFF
control
Remote ON/OFF
Leave open if not used
• Power ON with dimming:
DIM ~ -Vin >2.5~6VDC or open circuit
• Power OFF:
DIM ~ -Vin <0.8VDC or short
• Power ON with dimming:
DIM ~ -Vin >2~10VDC or open circuit
• Power OFF:
DIM ~ -Vin <0.5VDC or short
PWM frequency 100~1KHz 1KHz
Short circuit Regulated at rated output current, can be continued, auto-recovery
Over temperature protection Shut down, recovers automatically after temperature goes down
Working temperature
-40~+85
o
C (refer to output derating curve) -40~+71
o
C (refer to output derating curve)
EMC standards EN55015, EN61547, EN61000-4-2,3,4,6,8, FCC part 15 class B
Operating case temp. (max.) 100
o
C110
o
C
Dimension
(LxWxH)(mm)
LDD-H/HW: 31.8x 20.3x 12.2
LDD-HS: 31.8x 20.3x 11.4
31.8x 20.3x 12.2
LDD-H Series
LDB-L Series
LDB-300~600L/LW
