Special Control SiE39-407
90 Function
3.5 Standby
3.5.1 Restart Standby
Used to forcedly stop the compressor for a period of five minutes, in order to prevent the frequent ON/OFF of the
compressor and equalize the pressure within the refrigerant system.
* Actuators are based on RXYQ16MA.
3.5.2 Crankcase Heater Control
In order to prevent the refrigerant from dwelling in the compressor in the stopped mode, this mode is used to control the
crankcase heater.
Actuator Operation Remarks
Compressor OFF ⎯
Outdoor unit fan
Ta>30°C: STEP4
Ta≤30°C: OFF
⎯
Four way valve Holds ON ⎯
Main motorized valve (EV1) 0 pls ⎯
Subcooling motorized valve (EV2) 0 pls ⎯
Hot gas bypass valve (SVP) OFF
In the case of RXYQ5MA, this valve
turns ON.
Receiver gas discharging valve (SVG) OFF ⎯
Non-operating unit liquid pipe stop
valve (SVSL)
ON ⎯
Ending conditions 5 min. ⎯
Crankcase heater
OFF
Crankcase heater
ON
Discharge pipe
temperature < 70
°C
Discharge pipe
temperature > 75
°C
