Specifications SiE39-407
32 Specifications
Ceiling Mounted Built-in Type
Notes:
H1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
H2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
H3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length: 7.5m, level difference:
0m. (Heat pump only)
H4 Static external pressure is changeable to change over the connectors inside electrical box, this pressure
means
“High static pressure-Standard -Low static pressure”.
H5 Static external pressure is changeable to change over the connectors inside electrical box, this pressure
means
“High static pressure-Standard”.
6 Capacities are net, including a deduction for cooling (an additional for heating) for indoor fan motor heat.
H7 Anechoic chamber conversion value, measured at a point 1.5m downward from the unit center. These
values are normally somewhat higher during actual operation as a result of ambient conditions.
Model FXSQ80MVE FXSQ100MVE FXSQ125MVE
H1 Cooling Capacity (19.5°CWB)
kcal/h 8,000 10,000 12,500
Btu/h 31,800 39,700 49,600
kW 9.3 11.6 14.5
H2 Cooling Capacity (19.0°CWB) kW 9.0 11.2 14.0
H3 Heating Capacity
kcal/h 8,600 10,800 13,800
Btu/h 34,100 42,700 54,600
kW 10.0 12.5 16.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 300×1,400×800 300×1,400×800 300×1,400×800
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×14×1.75 3×14×1.75 3×14×1.75
Face Area m² 0.338 0.338 0.338
Fan
Model 3D18H2A 3D18H2A 3D18H2A
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number of
Units
W 225×1 225×1 225×1
Air Flow Rate (H/L) m³/min 27/21.5 28/22 38/28
H5 Static external
pressure
Pa 113-82 107-75 78-39
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber Glass Fiber Glass Fiber
Air Filter Resin Net (with Mold Resistant) Resin Net (with Mold Resistant) Resin Net (with Mold Resistant)
Piping
Connections
Liquid Pipes mm φ9.5 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ15.9 (Flare Connection) φ15.9 (Flare Connection) φ15.9 (Flare Connection)
Drain Pipe mm
VP25
(External Dia. 32 Internal Dia. 25)
VP25
(External Dia. 32 Internal Dia. 25)
VP25
(External Dia. 32 Internal Dia. 25)
Machine Weight (Mass) kg 51 51 52
H7 Sound Level (H/L) dBA 43/37 43/37 46/41
Safety Devices
Fuse,
Thermal Protector for Fan Motor
Fuse,
Thermal Protector for Fan Motor
Fuse,
Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R410A M Series R410A M Series R410A M Series
Decoration
Panel
(Option)
Model
BYBS125DJW1 BYBS125DJW1 BYBS125DJW1
Panel Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 55×1,500×500 55×1,500×500 55×1,500×500
Weight kg 6.5 6.5 6.5
Standard Accessories
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws, Washers.
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws, Washers.
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws, Washers.
Drawing No. 3D039431
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
