SiE39-407 Refrigerant Circuit
Refirgerant Circuit 53
RXYQ8MA, 10MA, 12MA
Stop valve (with service port ø 7.9 mm flaire connection)
Filter
Filter
Solenoid
valve
Heat
exchanger pipe
Electronic
expansion
valve
Fusible plug
Filter
Filter
Electronic
expansion valve
Check
valve
Solenoid
valve
Check
valve
Pressure regulating valve
(check valve type)
Filter
Four way
valve
Check
valve
Solenoid
valve
Filter
Filter
Check
valve
High pressure
sensor
Filter
High pressure
switch
Filter
Receiver
SENPH
HPS
Oil
separator
Compressor
INV STD1
Capillary tube
Compressor
Capillary tube
Gauge port
SENPL
Low pressure
sensor
Oil
separator
HPS
3D048033A
E
S
J
SV
SV
SV
7
V
U
L
6
F
P
3
2
A
W
X
B
O
4
5
D
1
N
M
Q
