SiE39-407 Specifications
Specifications 11
Notes:
H1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
H2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
H3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference
: 0m.
Model Name RXYQ10MAY1 RXYQ12MAY1
H1 Cooling Capacity (19.5°CWB)
kcal / h 24,300 29,000
Btu / h 96,300 115,000
kW 28.2 33.7
H2 Cooling Capacity (19.0°CWB) kW 28.0 33.5
H3 Heating Capacity
kcal / h 27,000 32,300
Btu / h 108,000 128,000
kW 31.5 37.5
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm 1600×930×765 1600×1240×765
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 13.72+10.53 13.72+10.53
Number of Revolutions r.p.m 6480, 2900 6480, 2900
Motor Output×Number
of Units
kW (1.6+4.5)×1 (2.8+4.5)×1
Starting Method Direct on line Direct on line
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×1 0.75×1
Air Flow Rate m³/min 180 210
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ9.5 (Flare Connection) φ12.7 (Flare Connection)
Gas Pipe mm φ22.2 (Brazing Connection) φ28.6 (Brazing Connection)
Product Mass (Machine Weight) kg 230 268
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
Defrost Method Deicer Deicer
Capacity Control % 14~100 14~100
Refrigerant
Refrigerant Name R410A R410A
Charge kg 8.6 10.4
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. C: 4D048270 C: 4D048271
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
