Selection of Pipe Size, Joints and Header SiE39-407
318 Appendix
6.2.6 Outdoor Unit Multi Connection Piping Kit
Select the piping kit according to the No. of outdoor units
6.2.7 Piping between REFNET Joint and Indoor Unit
Pipe size for direct connection to indoor unit must be the same as the connection size of indoor
unit.
6.2.8 Piping between outdoor Unit and Multi Connection Piping Kit
Pipe size for direct connection to outdoor unit must be the same as the connection size of
outdoor unit.
No. of outdoor units Multi Connection Piping Kit
2 units
BHFP22M90
BHFP22M90P
3 units
BHFP22M135
BHFP22M135P
Connection pipe size of indoor unit.
Indoor Units Gas Liquid
20 · 25 · 32 · 40 · 50 Type φ12.7 φ6.4
63 · 80 · 100 · 125 Type φ15.9
φ9.5200 Type φ19.1
250 Type φ22.2
Outdoor Units Gas Liquid Oil
RXYQ8MAY1 φ19.1
φ9.5
φ6.4RXYQ10MAY1 φ22.2
RXYQ12MAY1-16MAY1 φ28.6 φ12.7
