Protection Control SiE39-407
96 Function
4.3 Discharge Pipe Protection Control
This discharge pipe protection control is used to protect the compressor internal temperature
against a malfunction or transient increase of discharge pipe temperature.
H Each compressor performs the discharge pipe temperature protection control individually
in the following sequence.
[INV compressor]
[STD compressor]
or
Normal operation
INV62 Hz + OFF + OFF
or
Every 30 sec.
or
&
Every 60 sec.
or
&
Discharge pipe
temperature standby (for
a period of 10 minutes)
INV upper limit frequency:
1-step down from current
compressor frequency
HTdi>115°C
Tp>140°C
HTdi>115°C
Tp>140°C
HTdi>130°C
HTdi>120°C
for 90 sec.
or more.
Tp>130°C
In discharge pipe temp.
protection control
HTdi<100°C
Tp<110°C
HTdi<110°C
Tp<125°C
HTdi>135°C
HTdi>120°C for 10 min. or more.
INV upper limit frequency: 1-step up
from current compressor frequ
ency
When occurring 3 times within 100 minutes,
the malfunction code “F3” is output.
HTdi : Value of INV compressor discharge pipe
temperature (Tdi) compensated with
outdoor air temperature
Tp : Value of compressor port temperature
calculated by Tc and Te, and suction
superheated degree.
or
Discharge pipe temp.
protection control not limited
10 min.
• HTds>120°C continues for 5 min. or more.
• HTds>135°C
• Tp>140°C continues for 10 min. or more.
• Tp>150°C
Applicable STD
compressor stops.
HTds: Value of STD compressor discharge
pipe temperature (Tds) compensated
with outdoor air temperature
Tp: Value of compressor port temperature
calculated by Tc
and
Te, and suction
superheated degree.
