Daikin RXYQ14MAY1 [145/352] How to select operation mode
![Daikin RXYQ14MAY1 [145/352] How to select operation mode](/views2/1712502/page145/bg91.png)
Field Setting SiE39-407
134 Test Operation
How to Select
Operation Mode
Whether operation by remote controller will be possible or not for turning on/off, controlling
temperature or setting operation mode is selected and decided by the operation mode given on
the right edge of the table below.
Do not select “timer operation possible by remote controller” if not using a remote controller.
Operation by timer is impossible in this case.
∗1. Factory setting
ON by remote
control
(Unified ON by
central remote
control)
OFF by remote
control
(Unified OFF by
central remote
control)
Temperature
control by
remote control
Operation mode
setting by
remote control
OFF by
remote
control
Example
(VL069)
Control
mode is "1."
↓
Acceptance
↓
Acceptance
↓
Rejection
↓
Rejection
↓
Rejection
Control mode Control by remote controller Control mode
Operation OFF Temperature
control
Operation
mode setting
Unified operation,
individual operation
by central remote
controller, or
operation controlled
by timer
Unified OFF,
individual stop by
central remote
controller, or timer
stop
ON/OFF control
impossible by
remote controller
Rejection (Example) Rejection (Example) Rejection
(Example)
Rejection Acceptance 0
Rejection 10
Acceptance
(Example)
Acceptance
(Example)
1(Example)
Rejection 11
OFF control only
possible by
remote controller
Acceptance Rejection Acceptance 2
Rejection 12
Acceptance Acceptance 3
Rejection 13
Centralized Acceptance Rejection Acceptance 4
Rejection 14
Acceptance Acceptance 5
Rejection 15
Individual Acceptance Rejection Acceptance 6
Rejection 16
Acceptance Acceptance 7 ∗1
Rejection 17
Timer operation
possible by
remote controller
Acceptance
(During timer at ON
position only)
Acceptance
(During timer at ON
position only)
Rejection Acceptance 8
Rejection 18
Acceptance Acceptance 9
Rejection 19
When the operation,
stop, temperature
setting and operation
mode setting by remote
control are rejected,
“ ” is
displayed on the
remote control.
(VL070)
