Selection of Pipe Size, Joints and Header SiE39-407
316 Appendix
6.2 RXYQ18MAY1, RXYQ20MAY1, RXYQ22MAY1,
RXYQ24MAY1, RXYQ26MAY1, RXYQ28MAY1,
RXYQ30MAY1, RXYQ32MAY1, RXYQ34MAY1,
RXYQ36MAY1, RXYQ38MAY1, RXYQ40MAY1,
RXYQ42MAY1, RXYQ44MAY1, RXYQ46MAY1,
RXYQ48MAY1
6.2.1 How to select the REFNET Joint
How to select the REFNET Joint
Select the REFNET Joint from the following table.When using REFNET Joints at the first branch
counted from the outdoor unit side.
For REFNET Joints other than the first branch, select the proper ones based on the total
capacity index of the indoor units installed after the first branch using the following table :
6.2.2 How to select pipe size
Main Piping (Between Multi connection piping kit and REFNET Joint)
Select the proper ones based on the following table :
Piping Material
Select the piping material to be used from the next table according to piping size.
(Ex. : REFNET Joint A)
Outdoor Unit REFNET Joint (Kit Name)
RXYQ18MAY1-22MAY1 KHRP26M72T
RXYQ24MAY1-48MAY1 KHRP26M73T
Total capacity index of indoor units REFNET Joints (Kit Name)
<200 KHRP26M22T
≥200~<290 KHRP26M33T
≥290 KHRP26M72T
≥640 KHRP26M73T
Outdoor Unit Gas Liquid
RXYQ18MAY1
φ28.6
φ15.9
RXYQ20MAY1
RXYQ22MAY1
RXYQ24MAY1
φ34.9
RXYQ26MAY1
φ19.1
RXYQ28MAY1
RXYQ30MAY1
RXYQ32MAY1
RXYQ34MAY1
RXYQ36MAY1
φ41.3
RXYQ38MAY1
RXYQ40MAY1
RXYQ42MAY1
RXYQ44MAY1
RXYQ46MAY1
RXYQ48MAY1
Piping Size (O / D) Temper grade of Material
φ15.9 or less O * O: Soft (Annealed)
φ19.1 or more 1 / 2H or H * H: Hard (Drawn)
