Option List SiE39-407
310 Appendix
System Configuration
Note:
Installation box for
H adaptor must be procured on site.
Building management system
Notes:
H
1. PPD does not support Connection Unit Series.
H
2. BACnet
®
is a registered trademark of American Society of Heating, Refrigerating and
Air-Conditioning Engineers (ASHRAE).
H
3. LON WORKS
®
is a registered trade mark of Echelon Corporation.
No. Part name Model No. Function
1 Central remote controller DCS302C61
Up to 64 groups of indoor units (128 units)can be connected, and ON/OFF, temperature
setting and monitoring can be accomplished individually or simultaneously. Connectable up
to “2” controllers in one system.
2 Unified ON/OFF controller DCS301B61
Up to 16 groups of indoor units (128 units) can be turned, ON/OFF individually or
simultaneously, and operation and malfunction can be displayed. Can be used in
combination with up to 8 controllers.
3 Schedule timer DST301B61
Programmed time weekly schedule can be controlled by unified control for up to 64 groups
of indoor units (128 units). Can turn units ON/OFF twice per day.
4
Unification adaptor for computerized
control
HDCS302A52 Interface between the central monitoring board and central control units
5 Interface adaptor for SkyAir-series HDTA102A52
Adaptors required to connect products other than those of the VRV System to the high-
speed DIII-NET communication system adopted for the VRV System.
To use any of the above optional controllers, an appropriate adaptor must be installed on
the product unit to be controlled.
6 Central control adaptor kit HDTA107A55
7 Wiring adaptor for other air-conditioner HDTA103A51
8
DIII-NET
Expander adaptor
DTA109A51
Up to 1,024 units can be centrally controlled in 64 different groups.
Wiring restrictions (max. length : 1,000m, total wiring length : 2,000m, max. number of
branches : 16) apply to each adaptor.
9 Mounting plate KRP4A92 Fixing plate for DTA109A51
No. Part name Model No. Function
1
intelligent Touch
Controller
basic Hardware
intelligent
Touch
Controller
DCS601C51
• Air-Conditioning management system that can be controlled by a
compact all-in-one unit.
1-1
Option
Hardware
DIII-NET
plus
adaptor
DCS601A52 • Additional 64 groups (10 outdoor units) is possible.
1-2
Software
P.P.D. DCS002C51 • P.P.D.: Power Proportional Distribution function
1-3 Web DCS004A51
• Monitors and controls the air conditioning system using the Internet
and Web browser application on a PC.
1-4 Electrical box with earth terminal (4blocks) KJB411A • Wall embedded switch box.
2
intelligent Manager
ECO 21
Number of
units to be
connected
128 units DAM602A52
Air conditioner management system (featuring minimized engineering)
that can be controlled by personal computers.
192 units DAM602A53
256 units DAM602A51
512 units DAM602A51x2
768 units DAM602A51x3
1024 units DAM602A51x4
2-1
Communication
Line
Optional DIII Ai unit DAM101A51
Analog input for "sliding temperature" function (to reduce cold shock) for
intelligent Manager EC021.
3 H2 Interface for use in BACnet
®
DMS502A51
Interface unit to allow communications between VRV and BMS.
Operation and monitoring of air-conditioning systems through BACnet
®
communications.
3-1 Optional DIII board DAM411A1
Expansion kit, installed on DMS502A51, to provide 3 more DIII-NET
communication ports. Not usable independently.
3-2 Optional Di board DAM412A1
Expansion kit, installed on DMS502A51, to provide 16 more wattmeter
pulse input points. Not usable independently.
4 H3 Interface for use in L
ON WORKS
®
DMS504B51
Interface unit to allow communications between VRV and BMS.
Operation and monitoring of air-conditioning systems through
LON WORKS
®
communication.
5
Contact/Analog signal
Parallel
interface
Basic unit DPF201A51
Enables ON/OFF command, operation and display of malfunction; can be used
in combination with up to 4 units.
6
Temperature
measurement units
DPF201A52 Enables temperature measurement output for 4 groups; 0-5VDC.
7 Temperature setting units DPF201A53 Enables temperature setting input for 16 groups; 0-5VDC.
8
Unification adaptor for computerized
control
DCS302A52 Interface between the central monitoring board and central control units
9-1
Wiring adaptor for electrical
appendices (1)
KRP2A53, 61, 62
Simultaneously controls air-conditioning control computer and up to 64 groups of
indoor units.
9-2
Wiring adaptor for electrical
appendices (2)
KRP4A51-54
To control the group of indoor units collectively, which are connected by the
transmission wiring of remote controller.
13
External control adaptor for outdoor
unit (Must be installed on indoor units.)
DTA104A53, 61,
62
Cooling/Heating mode change over. Demand control and Low noise control are
available between the plural outdoor units.
