Daikin RXYQ14MAY1 [111/352] Emergency operation
![Daikin RXYQ14MAY1 [111/352] Emergency operation](/views2/1712502/page111/bg6f.png)
Other Control SiE39-407
100 Function
5.2 Emergency Operation
If the compressor cannot operate, this control inhibits any applicable compressor or outdoor unit
from operating to perform emergency operation only with the operative compressor or outdoor
unit.
5.2.1 Restrictions for Emergency Operation
• In the case of system with 1 outdoor unit installed, only when thermostats of indoor units
having a capacity of 50% or more of the outdoor unit capacity turn ON, the emergency
operation is functional. (If the total capacity of indoor units with thermostat ON is small, the
outdoor unit cannot operate.)
• If the emergency operation is set while the outdoor unit is in operation, the outdoor unit stops
once after pump-down residual operation (a maximum of 5 minutes elapsed).
5.2.2 In the Case of 1-Outdoor-Unit System (RXYQ8MA to 16MA)
Set the system to operation prohibition mode by compressor.
• In order to set an INV compressor to operation
prohibition mode, set No. 42 of Setting mode 2 to
"EMERGENCY OPERATION".
(Procedure)
(1) Press and hold the PAGE button (BS1) for a period
of 5 seconds or more.
(2) Press the OPERATION button (BS2) 42 times.
(3) Press the CHECK button (BS3) once.
(4) Press the OPERATION button (BS2) once.
(5) Press the CHECK button (BS3) twice.
(6) Press the PAGE button (BS1) once.
• In order to set STD1 and STD 2 compressors to
operation prohibition mode, set No. 19 of Setting
mode 2 to "STD1, 2 OPERATION PROHIBITION".
(RXYQ8MA to 16MA)
(Procedure)
(1) Press and hold the PAGE button (BS1) for a period
of 5 seconds or more.
(2) Press the OPERATION button (BS2) 19 times.
(3) Press the CHECK button (BS3) once.
(4) Press the OPERATION button (BS2) once.
(5) Press the CHECK button (BS3) twice.
(6) Press the PAGE button (BS1) once.
• In order to set the STD 2 compressor to operation
prohibition mode, set No. 19 of Setting mode 2 to "STD2
OPERATION PROHIBITION".(RXYQ14MA, 16MA)
(Procedure)
(1) Press and hold the PAGE button (BS1) for a period
of 5 seconds or more.
(2) Press the OPERATION button (BS2) 19 times.
(3) Press the CHECK button (BS3) once.
(4) Press the OPERATION button (BS2) twice.
(5) Press the CHECK button (BS3) twice.
(6) Press the PAGE button (BS1) once.
Caution
In order to disable the compressor operation due to a failure or else, be sure to do so
in emergency operation mode.
NEVER attempt to disconnect power supply wires from magnetic contactors or else.
(Doing so will operate compressors in combination that disables oil equalization
between the compressors, thus resulting in malfunctions of other normal
compressors.)
(Factory set)
7
777777
777777
77
7
77
7
77
7
7
77777
77777
9
7
7777
7777
97
7
777777
777777
77
777
7777
7777
LED display (
7
:ON
7
:OFF
9
:Blink)
H1P
---
H7P
(Factory set)
7
777777
777777
7
7
77
77
7777
7
777777
777777
7
77777
77777
9
7
777777
777777
77
777
7777
7777
LED display (
7
:ON
7
:OFF
9
:Blink)
H1P
---
H7P
(Factory set)
7
777777
777777
7
7
77
77
7777
7
777777
777777
7
7777
7777
97
7
777777
777777
77
777
7777
7777
LED display (
7
:ON
7
:OFF
9
:Blink)
H1P
---
H7P
