Protection Control SiE39-407
94 Function
4. Protection Control
4.1 High Pressure Protection Control
This high pressure protection control is used to prevent the activation of protection devices due
to abnormal increase of high pressure and to protect compressors against the transient
increase of high pressure.
[In cooling operation]
H In the case of multi-outdoor-unit system, each outdoor unit performs this control
individually in the following sequence.
[In heating operation]
H In the case of multi-outdoor-unit system, the entire system performs this control in the
following sequence.
High pressure not limited
Pc>3.47MPa
High pressure standby
High pressure limited
Pc>3.47MPa
Pc>3.64MPa
Pc<3.24MPa
Pc>3.55MPa
INV upper limit frequency :
3-step / 10 sec down from
current compressor frequency
INV upper limit frequency:
1-step / 20 sec up from
current compressor frequency
STD compressor
standby for 5 mins
INV upper limit frequency = 210 Hz
Pc: HP pressure sensor detection
value for each outdoor unit
When occurring 3 times within
30 min., HPS is activated without high
pressure standby, th us outputting the
malfunction code “E3”.
High pressure not limited
Pc>3.32MPa
Lower-priority compressor stops.
High pressure limited
Pc>3.32MPa
Pc>3.42MPa
High pressure standby
Pc>3.64MPa
Pc<2.9MPa
Master unit: 52 Hz + OFF + OFF
Slave unit: All units stop.
Pc: HP pressure sensor detection
value for master unit
When occurring 3 times within
30 min., HPS is activated without high
pressure standby, thus outputting the
malfunction code “E3”.
