SiE39-407 List of Electrical and Functional Parts
Appendix 301
3. List of Electrical and Functional Parts
3.1 Outdoor Unit
3.1.1 RXYQ5MAY1~16MAY1
Item Name Symbol
Model
RXYQ5MAY1 RXYQ8MAY1 RXYQ10MAY1
Compressor
Inverter
Type
M1C
JT1G-VDKYR@T
OC protection
device
13.5A
STD 1
Type
M2C —
JT170G-KYE@T
OC protection
device
15.0A
STD 2
Type
M3C —
OC protection
device
Fan motor
OC protection
device
M1F 0.9A 1.3A
Electronic expansion valve (Main) Y1E Fully closed: 0pls Fully open: 2000pls
Electronic expansion valve (Subcool) Y2E Fully closed: 0pls Fully open: 2000pls
Pressure
protection
High pressure
switch
For M1C S1PH OFF: 4.0 MPa ON: 3.0±0.15MPa
For M2C S2PH —
OFF: 4.0 MPa
ON: 3.0±0.15MPa
For M3C S3PH —
Low pressure sensor SLNPL OFF: 0.07MPa
Fusible plug — Open: 70~75°C
Temperature
protection
Discharge gas temperature
protection
(Discharge pipe thermistor)
R3T OFF: 135°C
Inverter fin temperature
protection
(Radiator fin thermistor)
R1T OFF: 98°C
Others Fuse
For main PC
board
F1U 250V AC 10A Class B
F2U 250V AC 10A Class B
For Noise filter
PC board
F1U 250V AC 5A Class B
+0
−0.12
+0
−0.12
