Specifications SiE39-407
46 Specifications
Floor Standing Type
Notes:
H1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
H2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
H3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length: 7.5m, level difference:
0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
H5 Anechoic chamber conversion value, measured at a point 1.5 m in front of the unit at a height of 1.5 m.
During actual operation, these values are normally somewhat higher as a result of ambient conditions.
Model FXLQ40MHV1 FXLQ50MHV1
H1 Cooling Capacity (19.5°CWB)
kcal/h 4,000 5,000
Btu/h 15,900 19,900
kW 4.7 5.8
H2 Cooling Capacity (19.0°CWB) kW 4.5 5.6
H3 Heating Capacity
kcal/h 4,300 5,400
Btu/h 17,000 21,500
kW 5.0 6.3
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm 600×1,140×222 600×1,420×222
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×14×1.5 3×14×1.5
Face Area m² 0.200 0.282
Fan
Model 2D14B13 2D14B20
Type Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 25×1 35×1
Air Flow Rate (H/L)
m³/min 11/8.5 14/11
cfm 388/300 494/388
Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber/ Urethane Foam Glass Fiber/ Urethane Foam
Air Filter Resin Net (with Mold Resistant) Resin Net (with Mold Resistant)
Piping
Connections
Liquid Pipes mm φ6.4 (Flare Connection) φ6.4 (Flare Connection)
Gas Pipes mm φ12.7 (Flare Connection) φ12.7 (Flare Connection)
Drain Pipe mm φ21 O.D (Vinyl Chloride) φ21 O.D (Vinyl Chloride)
Machine Weight (Mass) kg 30 36
H5 Sound Level (H/L) dBA 38/33 39/34
Safety Devices Thermal Protector for Fan Motor Thermal Protector for Fan Motor
Refrigerant Control — —
Connectable Outdoor Unit R410A M Series R410A M Series
Standard Accessories
Operation Manual, Installation Manual, Insulation for
Fitting, Drain Hose, Clamps, Screws, Washers, Level
Adjustment Screw.
Operation Manual, Installation Manual, Insulation for
Fitting, Drain Hose, Clamps, Screws, Washers, Level
Adjustment Screw.
Drawing No. 3D047065
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
