SiE39-407 Option List
Appendix 311
4.2 Option Lists (Outdoor Unit)
RXYQ5MAY1 ~ 16MAY1
3D047968A
RXYQ18MAY1 ~ 32MAY1
3D047968A
RXYQ34MAY1 ~ 48MAY1
3D047968A
Optional accessories RXYQ5MAY1
RXYQ8MAY1
RXYQ10MAY1
RXYQ12MAY1
RXYQ14MAY1
RXYQ16MAY1
Cool/Heat Selector KRC19-26A
Cool/Heat
Selector
Fixing box KJB111A
Distributive
Piping
Refnet header
KHRP26M22H,
KHRP26M33H
(Max. 4 branch)
(Max. 8 branch)
KHRP26M22H,
KHRP26M33H,
(Max. 4 branch)
(Max. 8 branch)
KHRP26M22H,
KHRP26M33H,
(Max. 4 branch)
(Max. 8 branch)
KHRP26M72H
(Max. 8 branch)
Refnet joint
KHRP26M22T KHRP26M22T,
KHRP26M33T,
KHRP26M22T,
KHRP26M33T,
KHRP26M72T
Central drain pan kit KWC26B160 KWC26B280 KWC26B450
Optional accessories
RXYQ18MAY1
RXYQ20MAY1
RXYQ22MAY1
RXYQ24MAY1
RXYQ26MAY1
RXYQ28MAY1
RXYQ30MAY1
RXYQ32MAY1
Cool/Heat Selector KRC19-26A
Cool/Heat
Selector
Fixing box KJB111A
Distributive
Piping
Refnet header
KHRP26M22H, KHRP26M33H, KHRP26M72H, KHRP26M73H
(Max. 4 branch) (Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
Refnet joint KHRP26M22T, KHRP26M33T, KHRP26M72T, KHRP26M73T
Outdoor unit multi connection piping kit BHFP22MA90
Pipe size reducer KHRP26M73TP, KHRP26M73HP
Central drain pan kit KWC26B280 × 2
KWC26B280
KWC26B450
KWC26B450 × 2 KWC26B450 × 2
Optional accessories
RXYQ34MAY1
RXYQ36MAY1
RXYQ38MAY1
RXYQ40MAY1
RXYQ42MAY1
RXYQ44MAY1
RXYQ46MAY1
RXYQ48MAY1
Cool/Heat Selector KRC19-26A
Cool/Heat
Selector
Fixing box KJB111A
Distributive
Piping
Refnet header
KHRP26M22H, KHRP26M33H, KHRP26M72H, KHRP26M73H
(Max. 4 branch) (Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
Refnet joint KHRP26M22T, KHRP26M33T, KHRP26M72T, KHRP26M73T
Outdoor unit multi connection piping kit BHFP22MA135
Pipe size reducer KHRP26M73TP, KHRP26M73HP
Central drain pan kit
KWC26B280 × 2
KWC26B450
KWC26B280
KWC26B450 × 2
KWC26B280
KWC26B450 × 2
KWC26B450 × 3
