SiE39-407 Specifications
Specifications 41
Concealed Floor Standing Type
Notes:
H1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
H2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
H3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length: 7.5m, level difference:
0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
H5 Anechoic chamber conversion value, measured at a point 1.5 m in front of the unit at a height of 1.5 m.
During actual operation, these values are normally somewhat higher as a result of ambient conditions.
Model FXNQ40MVE FXNQ50MVE FXNQ63MVE
H1 Cooling Capacity (19.5°CWB)
kcal/h 4,000 5,000 6,300
Btu/h 15,900 19,900 25,000
kW 4.7 5.8 7.3
H2 Cooling Capacity (19.0°CWB) kW 4.5 5.6 7.1
H3 Heating Capacity
kcal/h 4,300 5,400 6,900
Btu/h 17,000 21,500 27,300
kW 5.0 6.3 8.0
Casing Color Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 610×1,070×220 610×1,350×220 610×1,350×220
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×14×1.5 3×14×1.5 3×14×1.5
Face Area m² 0.200 0.282 0.282
Fan
Model 2D14B13 2D14B20 2D14B20
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 25×1 35×1 35×1
Air Flow Rate (H/L)
m³/min 11/8.5 14/11 16/12
cfm 388/300 494/388 565/424
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber / Urethane Foam Glass Fiber / Urethane Foam Glass Fiber / Urethane Foam
Air Filter Resin Net (with Mold Resistant) Resin Net (with Mold Resistant) Resin Net (with Mold Resistant)
Piping
Connections
Liquid Pipes mm φ6.4 (Flare Connection) φ6.4 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ12.7 (Flare Connection) φ12.7 (Flare Connection) φ15.9 (Flare Connection)
Drain Pipe mm φ21 O.D (Vinyl Chloride) φ21 O.D (Vinyl Chloride) φ21 O.D (Vinyl Chloride)
Machine Weight (Mass) kg 23 27 27
H5 Sound Level (H/L) dBA 38/33 39/34 40/35
Safety Devices
Fuse,
Thermal Protector for Fan Motor
Fuse,
Thermal Protector for Fan Motor
Fuse,
Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable Outdoor Unit R410A M Series R410A M Series R410A M Series
Standard Accessories
Operation Manual, Installation
Manual, Insulation for Fitting, Drain
Hose, Clamps, Screws, Washers,
Level Adjustment Screw.
Operation Manual, Installation
Manual, Insulation for Fitting, Drain
Hose, Clamps, Screws, Washers,
Level Adjustment Screw.
Operation Manual, Installation
Manual, Insulation for Fitting, Drain
Hose, Clamps, Screws, Washers,
Level Adjustment Screw.
Drawing No. 3D038817
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
