Troubleshooting by Remote Controller SiE39-407
178 Troubleshooting
Malfunction
code
Operation
lamp
Inspection
display
Unit No. Malfunction contents Page
Referred
Indoor
Unit
A0 999Error of external protection device 182
A1 999PC board defect, E
2
PROM defect 183
A3 999Malfunction of drain level control system (33H) 184
A6 999Fan motor (MF) lock, overload 186
A7 879Malfunction of swing flap motor (MA) 187
A9 999Malfunction of moving part of electronic expansion
valve (20E)
189
AF 879Drain level about limit 191
AH 879Malfunction of air filter maintenance —
AJ 999Malfunction of capacity setting 192
C4 999Malfunction of thermistor (R2T) for heat exchange
(loose connection, disconnection, short circuit,
failure)
193
C5 999Malfunction of thermistor (R3T) for gas pipes (loose
connection, disconnection, short circuit, failure)
194
C9 999Malfunction of thermistor (R1T) for air inlet (loose
connection, disconnection, short circuit, failure)
195
CJ 888Malfunction of thermostat sensor in remote controller 196
Outdoor
Unit
E1 999PC board defect 197
E3 999Actuation of high pressure switch 198
E4 999Actuation of low pressure sensor 199
E5 999Compressor motor lock 200
E6 999Standard compressor lock or over current 201
E7 999Malfunction of outdoor unit fan motor 202
E9 999Malfunction of moving part of electronic expansion
valve (Y1E~3E)
204
F3 999Abnormal discharge pipe temperature 206
F6 999Refrigerant overcharged 207
H3 879Malfunction of High pressure switch —
H4 999Malfunction of Low pressure switch —
H7 999Abnormal outdoor fan motor signal 208
H9 999Malfunction of thermistor (R1T) for outdoor air (loose
connection, disconnection, short circuit, failure)
209
J2 999Current sensor malfunction 210
J3 999Malfunction of discharge pipe thermistor (R31~33T)
(loose connection, disconnection, short circuit,
failure)
211
J5 999Malfunction of thermistor (R2T) for suction pipe
(loose connection, disconnection, short circuit,
failure)
212
Outdoor
Unit
J6 999Malfunction of thermistor (R4T) for heat exchanger
(loose connection, disconnection, short circuit,
failure)
213
J7 999Malfunction of header thermistor —
J8 999Malfunction of thermistor (R7T) for oil equalizing pipe.
(loose connection, disconnection, short circuit,
failure)
214
J9 999Malfunction of receiver gas pipe thermistor (R5T) 215
JA 999Malfunction of discharge pipe pressure sensor 216
JC 999Malfunction of suction pipe pressure sensor 217
L0 999Inverter system error —
L4 999Malfunction of inverter radiating fin temperature rise 218
L5 999Inverter compressor motor grounding, short circuit 219
L6 999Compressor motor coil grounding on short circuit —
L8 999Inverter current abnormal 220
L9 999Inverter start up error 221
