SG-500 VPN Security Gateway User’s Manual
- 124 -
Define the required fields of IPSec Function
i:
To display the VPN connection status via icon。
Chart --
Meaning Not be applied Disconnect Connecting
Name:
The VPN name to identify the IPSec Autokey definition. The name must be the only one and cannot be
repeated.
Gateway IP:
The WAN interface IP address of the remote Gateway.
IPSec Algorithm:
To display the Algorithm way.
Configure:
Click Modify to change the argument of IPSec; click Remove to remote the setting.
IPSec Autokey WebUI
