Planet SG-500 [41/319] Host table

SG-500 VPN Security Gateway User’s Manual

- 36 -

2.13 Host Table

STEP 1﹒ Select Host Table in Settings function and click on New Entry

 Domain Name: The domain name of the server

 Virtual IP Address: The virtual IP address respective to Host Table

 Click OK to add Host Table.

Add New Host Table

To use Host Table, the user PC’s first DNS Server must be the same as the LAN Port or DMZ Port IP

of SG-500. That is the default gateway.
