Planet SG-500 [319/319] Dhcp clients

SG-500 VPN Security Gateway User’s Manual

- 314 -

8.17 DHCP Clients

STEP 1﹒ In DHCP Clients of Status function, it will display the table of DHCP Clients that are

connected to the SG-500.

 IP Address: The dynamic IP that provided by DHCP Server

 MAC Address: The IP that corresponds to the dynamic IP

 Leased Time: The valid time of the dynamic IP (Start/End)

(Year/Month/Day/Hour/Minute/Second)

DHCP Clients Web UI
