SG-500 VPN Security Gateway User’s Manual
- 2 -
1.2 Package Contents
The following items should be included:
♦ VPN Security Gateway
♦ Power Adapter
♦ Quick Installation Guide
♦ User’s Manual CD
♦ RJ-45 cable
♦ Wall-mount kit
If any of the contents are missing or damaged, please contact your dealer or distributor immediately.
1.3 VPN Security Gateway Top View
LED Description
PWR Power is supplied to this device.
WAN Steady on indicates the port is connected to other network
device.
Blink to indicates there is traffic on the port
LAN Steady on indicates the port is connected to other network
device.
Blink to indicates there is traffic on the port
DMZ Steady on indicates the port is connected to other network
device.
Blink to indicates there is traffic on the port
1.4 VPN Security Gateway Rear Panel
Port or button Description
Power 12V DC, 1.5A
