SG-500 VPN Security Gateway User’s Manual
- 90 -
Define the required fields of Content Blocking
URL String:
The domain name that restricts to enter or only allow entering.
Popup Blocking:
Prevent the pop-up Web UI appearing
ActiveX Blocking:
Prevent ActiveX packets
Java Blocking:
Prevent Java packets
Cookies Blocking:
Prevent Cookies packets
eDonkey Blocking:
Prevent users to deliver files by eDonkey and eMule
BitTorrent Blocking:
Prevent users to deliver files by BitTorrent
WinMX Blocking:
Prevent users to deliver files by WinMX
Foxy Blocking:
Prevent users to deliver files by Foxy
