Инструкция по эксплуатации Страница: 61

Planet SG-500 [61/319] Setup a policy that only allows partial users to connect with specific ip external specific ip

SG-500 VPN Security Gateway User’s Manual

- 56 -

Setup a policy that only allows partial users to connect with specific IP (External

Specific IP)

STEP 1﹒Setting several LAN network Address.

Setting Several LAN Network Address
