Planet SG-500 [90/319] Example

SG-500 VPN Security Gateway User’s Manual

- 85 -

4.10 Example

Setting specific users to connect with external network, only those pass the

authentication of policy.

（Adopt the built-in Auth User and Auth Group Function）

STEP 1﹒Setup several Auth User in Authentication.

Setting Several Auth Users Web UI

To use Authentication, the DNS Server of the user’s network card must be the same as the LAN

Interface Address of SG-500.
