Planet SG-500 [254/319] Define the required fields of status

SG-500 VPN Security Gateway User’s Manual

- 249 -

Define the required fields of Status:

User Name:

 Display authentication account which is used by client.

Real IP:

 Display the real IP which is used by client.

VPN IP:

 Display the IP which is distributed to client by SG-500.

Uptime:

 Display the connection time between Server and Client.

Configure:

 Can disconnect the SSL VPN connection.

Status Web UI
