SG-500 VPN Security Gateway User’s Manual
- 241 -
Set a FTP Server under DMZ NAT Mode and restrict the download bandwidth
from external and MAX. Concurrent Sessions.
STEP 1﹒Set a FTP Server under DMZ, which IP is 192.168.3.2 (The DMZ Interface Address
is192.168.3.1/24)
STEP 2﹒Enter the following setting in Virtual Server1 of Virtual Server function.
Setting up Virtual Server Corresponds to FTP Server
When using the function of Incoming or WAN to DMZ in Policy, strong suggests that cannot select
ANY in Service. It may be attacked by Hacker easily.
STEP 3﹒Enter the following in QoS.
QoS Setting
