SG-500 VPN Security Gateway User’s Manual

- 35 -

Chart

Meaning Update

successfully

Incorrect

username or

password

Connecting

to server

Unknown error

If System Administrator had not registered a DDNS account, click on Sign up then can enter the

website of the provider.

If you do not select Automatically fill in the WAN IP and then you can enter a specific IP in WAN

IP. Let DDNS to correspond to that specific IP address.
