SG-500 VPN Security Gateway User’s Manual
- 226 -
Option:
To display if every function of Policy is enabled or not. If the function is enabled and then the
chart of the function will appear (See the chart and illustration below)
Chart Name Illustration
Traffic Log Enable traffic log
Statistics Enable traffic statistics
Authentication User Enable Authentication User
Schedule
Enable the policy to automatically execute the
function in a certain time
Content Blocking Enable Content Blocking
QoS Enable QoS
Traffic Log:
Record all the packets that go through policy.
Statistics:
Chart of the traffic that go through policy
Content Blocking:
To restrict the packets that passes through the policy
Authentication-User:
The user have to pass the authentication to connect by Policy
Schedule:
Setting the policy to automatically execute the function in a certain time
