SG-500 VPN Security Gateway User’s Manual

- 288 -

Inbound Accounting Report

It is the statistics of downstream / upstream for all kinds of communication services. The Inbound

Accounting report will be shown when WAN users use SG-500 to connect with LAN Server.

Source IP：

 The IP address used by WAN users who use SG-500

Destination IP：

 The IP address used by LAN service server who use SG-500

Service：

 The communication service which listed in the menu when WAN users use SG-500 to connect

to LAN Service server.
