SG-500 VPN Security Gateway User’s Manual
- 293 -
STEP 3﹒Enter Outbound in Accounting Report and select Top Services to inquire the statistics
website of Send / Receive packets, Downstream/Upstream, First packet/Last
packet/Duration and the service from the WAN Server to pass the SG-500.
TOP：Select the data you want to view. It presents 10 results in one page.
：According to the downstream / upstream report of the selected TOP
numbering to draw the Protocol Distribution chart.
Pull-down menu selection
Service：The report of Communication Service when LAN users use the SG-500 to
connect to WAN service server.
Downstream：The percentage of downstream and the value of each WAN service
server who uses SG-500 to connect to LAN user.
Upstream：The percentage of upstream and the value of each LAN user who uses
SG-500 to WAN service server.
First Packet：When the first packet is sent to the WAN Service Server, the sent
time will be recorded by the SG-500.
Last Packet：When the last packet is sent from the WAN Service Server, the sent
time will be recorded by the SG-500.
Duration：The period of time starts from the first packet to the last packet to be
recorded.
Total Traffic：The SG-500 will record the sum of time and show the percentage of
each Communication Service’s upstream/downstream to WAN service server.
Reset Counter：Click the Reset Counter button to refresh the Accounting Report.
