SG-500 VPN Security Gateway User’s Manual

- 31 -

STEP 4﹒Adding successful. At this time the computer of 192.168.10.1/24, 192.168.20.1/24 and

192.168.1.1/24 can connect with each other and connect to Internet by NAT.
