SG-500 VPN Security Gateway User’s Manual
- 42 -
3.2 LAN
STEP 1﹒Select LAN in Interface and enter the following setting:
Enter the new IP Address and Netmask
Select Ping and HTTP
Click OK
Setting LAN Interface Web UI
The default LAN IP Address is 192.168.1.1. After the Administrator setting the new LAN IP Address
on the computer , he/she has to restart the System to make the new IP address effective (when the computer
obtain IP by DHCP).
Do not cancel Web UI selection before not setting Permitted IPs yet. It will cause the Administrator
cannot be allowed to enter the SG-500’s Web UI from LAN.
